Tire Size Designation |
Pattern |
Star Rating |
Ind Code |
Rim Width & Flange |
Min. Dual Spacing | Approximate Inflated Dimensions | Loaded Dimensions |
Tread Depth |
Performance Capability (TKPH) |
Type | |||||||||
Overall Width | Overall Diameter | Static Load Rad | |||||||||||||||||
in | mm | in | mm | in | mm | in | mm | 32nds | mm | T1 | T2 | T3 | TT | TL | |||||
14.00R24 | TB536 TB536 TB515 TB596 | * *** * * | G-2 E-2 G-2 G-2 | 10.00VA 10.00W 10.00VA 10.00VA | 17.7 17.7 17.7 17.7 | 450 450 450 450 | 14.8 14.8 14.8 14.8 | 375 375 375 375 | 53.9 53.9 53.9 53.9 | 1368 1368 1368 1368 | 31.5 31.5 31.5 31.5 | 25.0 25.0 25.0 25.0 |
110 |
140 |
170 | TL TL TL TL | |||
17.5R25 | TB515 TB596 | * * | G-2 G-2 | 14.00/1.5 14.00/1.5 | 17.5 17.5 | 445 445 | 53.1 53.1 | 1348 1348 | 24.0 | 610 | 34.0 35.3 | 27.0 28.0 | TL TL | ||||||
20.5R25 | TB515 TB596 | * * | G-2 G-2 | 17.00/2.0 17.00/2.0 | 20.5 20.5 | 521 521 | 58.8 58.8 | 1493 1493 | 26.3 | 669 | 37.8 39.1 | 30.0 31.0 | TL TL | ||||||
