• Deeper tread depth, longer service mileage.
• Big tread blocks with reinforced ribs, improved resistance to cuts and punctures.
• Mixed tread pattern, excellent traction and grip performance.
• Good stone ejection design.
• Designed for driving axle of dump trucks and cement-stirring trucks
Size |
PR | Loading Index |
Speed Rating |
Tread Depth (mm) |
Rim Width |
Alternative Rim | New Tire Inflated Dimensions (mm) | Max Load (Kg) |
Pressure (KPa) Single/Dual |
Tube |
Static Radius Under Load (mm) |
Min. Dual Tire Space (mm) | |||
12.00R20 | 20 | 156 | 153 | G | 23.0 | 8.50 | 8.50V, 9.00 | 315 | 1125 | 4000 | 3650 | 900 | TT | 516 | 372 |
12.00R20 | 22 | 158 | 155 | F | 23.0 | 8.50 | 8.50V, 9.00 | 315 | 1125 | 4250 | 3875 | 970 | TT | 516 | 372 |
