• Big tread blocks with reinforced ribs and narrow grooves to provide good cornering per-
formance and soft tread for excellent grip performance on snow ground. Straight tread block design, with deep and hollow narrow grooves, to guarantee grip performance.
• Curved tread groove design, good traction on snow and muddy grounds, variable pitch design to reduce noise and provide better ride comfort.
• Block design between tread centerline and shoulder, with special deep and hollow narrow grooves, improved cross-country performance and reduced tread block hard- ness in low temperature, good for winter use.
Size |
PR |
Loading Index |
Speed Rating | Tread Depth(mm) |
Standard Rim |
Alternative Rim | Section Width(mm) | Overall Diameter(mm) | Max Load(kg) |
Pressure (KPa) |
Tube |
LT225/75R16 | 10 | 115/112 | Q | 11.7 | 6J | 6½J | 223 | 744 | 1215/1120 | 550 | TL |
LT245/75R16 | 10 | 120/116 | Q | 11.7 | 7J | 6½J, 7½J | 248 | 774 | 1380/1260 | 550 | TL |
LT245/70R17 | 10 | 119/116 | Q | 11.7 | 7J | 6½J, 7½J, 8J | 248 | 776 | 1360/1250 | 550 | TL |
LT265/70R17 | 10 | 121/118 | Q | 11.7 | 8J | 7½J, 8½J | 272 | 804 | 1450/1320 | 550 | TL |
275/65R18 | 10 | 116 | Q | 11.7 | 8J | 7½J, 8½J | 279 | 815 | 1250 | 350 | TL |
